Schweitzer Engineering Laboratories SEL-387E - Page 544

H-16 IEC 61850 Communications Date Code 20080110
SEL-387E Instruction Manual
Logical Node (All
ICD File versions)
Status Relay Word
Bit
Comment
N32PIOC14 Op.general 50N32
Q32PIOC15 Op.general 50Q32
P1PTOC1 Str.general 51P1
P1PTOC1 Op.general 51P1T
P11PTOC2 Str.general 50P11
P11PTOC2 Op.general 50P11T
N1PTOC3 Str.general 51N1
N1PTOC3 Op.general 51N1T
N11PTOC4 Str.general 50N11
N11PTOC4 Op.general 50N11T
Q1PTOC5 Str.general 51Q1
Q1PTOC5 Op.general 51Q1T
Q11PTOC6 Str.general 50Q11
Q11PTOC6 Op.general 50Q11T
P2PTOC7 Str.general 51P2
P2PTOC7 Op.general 51P2T
P21PTOC8 Str.general 50P21
P21PTOC8 Op.general 50P21T
N2PTOC9 Str.general 51N2
N2PTOC9 Op.general 51N2T
N21PTOC10 Str.general 50N21
N21PTOC10 Op.general 50N21T
Q2PTOC11 Str.general 51Q2
Q2PTOC11 Op.general 51Q2T
Q21PTO12 Str.general 50Q21
Q21PTO12 Op.general 50Q21T
P3PTOC13 Str.general 51P3
P3PTOC13 Op.general 51P3T
P31PTOC14 Str.general 50P31
P31PTOC14 Op.general 50P31T
N3PTOC15 Str.general 51N3
