Schweitzer Engineering Laboratories SEL-387E - Page 554

H-26 IEC 61850 Communications Date Code 20080110
SEL-387E Instruction Manual
Logical Node
Ver 001
Ver 002L
Ver 002/002L
Status Relay
Word Bit
Comment
SVTGGIO6 SVTGGIO6 Ind11.stVal S3V3T
SVTGGIO6 SVTGGIO6 Ind12.stVal S3V4T
SVTGGIO6 SVTGGIO6 Ind13.stVal S3V5T
SVTGGIO6 SVTGGIO6 Ind14.stVal S3V6T
SVTGGIO6 SVTGGIO6 Ind15.stVal S3V7T
SVTGGIO6 SVTGGIO6 Ind16.stVal S3V8T
LTGGIO7 LTGGIO7 Ind01.stVal S1LT1
LTGGIO7 LTGGIO7 Ind02.stVal S1LT2
LTGGIO7 LTGGIO7 Ind03.stVal S1LT3
LTGGIO7 LTGGIO7 Ind04.stVal S1LT4
LTGGIO7 LTGGIO7 Ind05.stVal S2LT1
LTGGIO7 LTGGIO7 Ind06.stVal S2LT2
LTGGIO7 LTGGIO7 Ind07.stVal S2LT3
LTGGIO7 LTGGIO7 Ind08.stVal S2LT4
LTGGIO7 LTGGIO7 Ind09.stVal S3LT1
LTGGIO7 LTGGIO7 Ind10.stVal S3LT2
LTGGIO7 LTGGIO7 Ind11.stVal S3LT3
LTGGIO7 LTGGIO7 Ind12.stVal S3LT4
LTGGIO7 LTGGIO7 Ind13.stVal S3LT5
LTGGIO7 LTGGIO7 Ind14.stVal S3LT6
LTGGIO7 LTGGIO7 Ind15.stVal S3LT7
LTGGIO7 LTGGIO7 Ind16.stVal S3LT7
TLEDGGIO8 TLEDGGIO8 Ind01.stVal EN Front-panel target LED “EN”
TLEDGGIO8 TLEDGGIO8 Ind02.stVal TRIP Front-panel target LED
“TRIP”
TLEDGGIO8 TLEDGGIO8 Ind03.stVal INST Front-panel target LED
“INST”
TLEDGGIO8 TLEDGGIO8 Ind04.stVal 87-1 Front-panel target LED “87-1”
TLEDGGIO8 TLEDGGIO8 Ind05.stVal 87-2 Front-panel target LED “87-2”
TLEDGGIO8 TLEDGGIO8 Ind06.stVal 87-3 Front-panel target LED “87-3”
