Date Code 20080110 IEC 61850 Communications H-27
SEL-387E Instruction Manual
Logical Node
Ver 001
Ver 002L
Ver 002/002L
Status Relay
Word Bit
Comment
TLEDGGIO8 TLEDGGIO8 Ind07.stVal 24 Front-panel target LED “24”
TLEDGGIO8 TLEDGGIO8 Ind08.stVal 81 Front-panel target LED “87”
TLEDGGIO8 TLEDGGIO8 Ind09.stVal A Front-panel target LED “A”
TLEDGGIO8 TLEDGGIO8 Ind10.stVal B Front-panel target LED “B”
TLEDGGIO8 TLEDGGIO8 Ind11.stVal C Front-panel target LED “C”
TLEDGGIO8 TLEDGGIO8 Ind12.stVal N Front-panel target LED “N”
TLEDGGIO8 TLEDGGIO8 Ind13.stVal W1 Front-panel target LED “W1”
TLEDGGIO8 TLEDGGIO8 Ind14.stVal W2 Front-panel target LED “W2”
TLEDGGIO8 TLEDGGIO8 Ind15.stVal W3 Front-panel target LED “W3”
TLEDGGIO8 TLEDGGIO8 Ind16.stVal 50/51 Front-panel target LED
“50/51”
a
Active data only if additional I/O card(s) installed.
P ROTOCOL I MPLEMENTATION C ONFORMANCE S TATEMENT
The following tables are as shown in the IEC 61850 standard, Part 8-1, Section 24. Note that
since the standard explicitly dictates which services and functions must be implemented to
achieve conformance, only the optional services and functions are listed.
Table H.12: PICS for A-Profile Support
Profile Client Server Value/Comment
A1 Client/Server N Y
A2 GOOSE/GSE management Y Y Only GOOSE, not GSSE
Management
A3 GSSE N N
A4 Time Sync N N
Table H.13: PICS for T-Profile Support
Profile Client Server Value/Comment
T1 TCP/IP N Y
T2 OSI N N
T3 GOOSE/GSE Y Y Only GOOSE, Not GSSE
