Section 04 ENGINE (2-STROKE)
Subsection 04 (TOP END)
787 RFI Engines
F07D0US
27 Nm
(20 lbfft)
7
8
3
5
4
5
6
(34 rollers)
Engine oil
Loctite
243
Molykote
111
14
1
11
12
12
2
13
Loctite 243
Molykote
111
40 Nm
(30 lbfft)
9
10
30
Molykote 111
10 Nm
(89 lbfin)
15
16 17 19
18
20
Molykote
111
3 Nm
(27 lbfin)
21
29
27
8
26
25
24 23 22
Molykote 111
