SeaDoo GTX 4-TEC Supercharged User Manual

Section 13 PROPULSION
Subsection 01 (JET PUMP)
F18J0MA
Check for presence of water in cone and bearing.
If so, replace oil seal no. 7 and sleeve no. 14.
Remove both O-rings no. 20 and circlip.
F18J0NA
F18J0OA
Impeller
Remove ring no. 1 and impeller boot no. 2.
RXP Models
Unscrew boot no. 1 CLOCKWISE.
F19J06A
1
1. Unscrew clockwise
All Models
Replace ring or boot if damaged.
Mount impeller remover/installer in a vise.
MODEL TOOL P/N
GTX 4-TEC and
Supercharged
529 035 820
RXP 529 035 956
1
F18J0PB
1. Impeller remover/installer
642 smr2004-Complete Line Up
www.SeaDooManuals.net
