SeaDoo GTX 4-TEC Supercharged User Manual

Section 04 ENGINE (2-STROKE)
Subsection 01 (LEAK TEST)
F01B2UB
1
717 ENGINES — REAR VIEW
1. Engine drain hose blocked with a hose pincher
F01B2VA
2
3
1
717 ENGINES — FRONT VIEW
1. Loop hose and use clamps
2. Use two washers with exhaust manifold stud
3. Hose with adapter and nipple
3
21
F02E0DA
787 RFI ENGINES — REAR VIEW
1. Loop hose and use clamps
2. Hose with clamps. Install pump to the end
3. Block engine drain hose with a hose pincher
F02D0WA
1
787 RFI ENGINES — FRONT VIEW
1. Exhaust manifold plate
64 smr2004-Complete Line Up
www.SeaDooManuals.net

SeaDoo GTX 4-TEC Supercharged Specifications

General

Seating Capacity	3
Model	GTX 4-TEC Supercharged
Displacement	1494 cc
Manufacturer	Sea-Doo
Category	Personal Watercraft
Fuel Type	Unleaded gasoline
