HF Series Generators
Pre-Installation
PI-1005R3
5
METHOD OF MOUNTING
COMPONENT NORMAL METHOD OF MOUNTING
Generator Cabinet
Floor freestanding, wall mounted or anchor to floor with
four M10 (3/8”) bolts.
Control Consoles Desk freestanding, wall mounted or anchor to an optional pedestal.
Note: Anchoring hardware should be field supplied. For seismic areas all components must be anchored,
Local Standards should be applied.
MINIMUM RECOMMENDED FREE AREA FOR SERVICE ACCESS
SURFACE
COMPONENT
Left Side Right Side Front Rear Top Bottom
Generator Cabinet
50 cm
(20”)
50 cm
(20”)
100 cm
(40”)
--
(see note)
Completely
free
--
Control Consoles
10 cm
(4”)
10 cm
(4”)
Completely
free
10 cm
(4”)
Completely
free
--
Note: Ventilation conditions requires to keep a minimum free distance of 15 cm (6”) from both lateral sides of the Generator
Cabinet and also the same distance from the rear side when the Generator is provided with High Speed Starter (fans for the
starter module).
