HF Series Generators
Pre-Installation
PI-1005R3
18
3.7 BATTERY POWERED GENERATORS -- POWER LINE REQUIREMENTS
• Operation:
G Single-Phase at 110 / 208 / 230 / 240 VAC.
G Line voltage automatic compensation: ±15%.
G 50 Hz / 60 Hz.
• Thermomagnetic Interruptor / Circuit Breaker rating should be:
G 10 A (1P+N curve type D).
• Differential Sensitivity: 30 mA
• Minimum kW required:
G without Stand-Alone option: 2.2 kW
G with Stand-Alone option: 0.5 kW
• Line Impedance should comply with Standard IEC-60601.2.7.
3.8 BATTERY POWERED GENERATORS -- RECOMMENDED WIRE SIZE
The minimum recommended wire size for the line voltage is:
LINE VOLTAGE WIRE SIZE
110 VAC 4mm
2
AWG 12
208 / 230 / 240 VAC 2.5 mm
2
AWG 14
