Sedecal SHF-310 - Buckys (Optional); Tomo Device (Optional)

HF Series Generators
Installation
IN-1052R0
32
3.4.6 BUCKYS (OPTIONAL)
Connect the Bucky as indicated in the Section 5.2 (Interconnections Maps for
Buckys), and test them before connecting the Ion Chambers.
The following table represents the standard Bucky cable connections:
SYSTEM CABLE FROM BUCKY IS CONNECTED TO
Systems with 1 or 2 Bucky
Terminal Block 3TS1 of the Generator Cabinet
(Refer to Section 5.2 -- Bucky)
Systems with 3 or 4 Bucky
Terminal Block TB2 of the optional “Tomo / Bucky Adaptation Board”,
located in the Generator Cabinet
(Refer to “Tomo / Bucky Adaptation Board” and Section 5.2 -- Buckys).
The Bucky of a RAD only Table with Tomo Device
Terminal Block TB1 of the optional “Tomo / Bucky Adaptation Board”,
located in the Generator Cabinet
(Refer to “Tomo / Bucky Adaptation Board” and Section 5.2 -- Buckys).
Optional “Tomo / Bucky Adaptation Board” is required to install
more than two Buckys in the System. (Refer to the “Tomo / Bucky
Adaptation Board” and the Manual for the Bucky).
If the “Bucky Start” signal enters the Bucky through a relay or another inductive
device (a.e. a motor), it is mandatory to add the supplied R2--C2 close to each
Bucky, so they have to be connected on the terminal output of the Bucky
assembly. The R-Cs are attached to the Generator harness in a bag.
If “Bucky Start” signal enters the Bucky through an optocoupler, do not add the
suppliedR2--C2fortheBucky.
The operations described above w ill prevent noises and
uncontrolled Bucky movements that can cause exposure cutting
or console blocking.
3.4.7 TOMO DEVICE (OPTIONAL)
RAD Only T
able
The Tomo cable (A3083-01) from connector J13 of the “ATP Console CPU
Board” has to be connected to the Terminal Blocks TB1 and TB2 of the optional
“Tomo / Bucky Adaptation Board”, located in the Generator Cabinet.
The cables from the Tomo Device are also connected to the Terminal Blocks
TB1 and TB2 of the optional “Tomo / Bucky Adaptation Board”. Refer to the
“Tomo / Bucky Adaptation Board” for more detailed information and interface.
(Refer also to the Manuals of the Tomo Device).
RAD only Table requires the optional “Tomo / Bucky Adaptation
Board”.
