HF Series Generators
Configuration
CF-1018R3
4
1.1.3 3024SW3 - ATP CONSOLE CPU BOARD
Dip switch 3024SW3 is not used for configuration but all their switches must be
set in “Off” position.
1.1.4 3024SW4 - ATP CONSOLE CPU BOARD
Dip Switch 3024SW4 is not used for configuration but all their switches must be
set in “Off” position.
1.1.5 3000SW2 - HT CONTROLLER BOARD
HT Controller Dip Switches can be configured while the Generator is ON except
Dip Switch 3000SW2-1.
Set dip switch 3000SW2 as indicated in Table 1-3.
Table 1-3
Test Dip Switch 3000SW2 on the HT Controller Board in the Power Module
3000SW2
POSITION
OPEN (OFF) CLOSED (ON)
1 Normal.
Programming of Rotor Acceleration Time,
RAD Filament Setting Time, Fluoro Rotor and Filament
Hold-over Time
*1) *2)
2 Normal. Bypasses: Filament, Rotor Ready, Error E11.
*1) *3)
3 Normal -- Not used. Not used.
4 Normal -- Digital mA Loop Closed Digital mA Loop Open / Filament Current Constant
*1)
5 125 kV
*4)
150 kV
*4)
6 All Generators except Tube-2 for RAD Generators with Tube-2 for RAD only.
7 Filament Boosting for Tube--1 No Filament Boosting for Tube--1
*5)
8 Filament Boosting for Tube--2 No Filament Boosting for Tube--2
*5)
Notes.-- *1) Set in Closed (On) position only for Calibration and Testing procedures when indicated in the Service Manual.
*2) Note that SW2-1 in Closed (On) position is only set to program the Rotor Acceleration Time, Rad Filament Setting
Time, Fluoro Rotor and Filament Hold-over Time, therefore it changes the functions of Switches SW2-2 and SW2-4 to
SW2-8. Refer to S ection 3.
*3) This turns off the filaments so no radiation will be produced during the exposure.
WARNING: THE kV OUTPUT OF THE HV TRANSFORMER WILL BE WHATEVER IS SET BY THE CONSOLE. IF
THE X-RAY TUBE HV CABLES ARE NOT CONNECTED INTO THE HV TRANSFORMER, FILL COMPLETELY BOTH
HV RECEPTACLES WITH HV OIL.
*4) Set SW2-5 according to the Generator kV rating (refer to the Generator model and/or specifications).
*5)
Set to “No Filament Boosting” when using X-ray Tubes with Small Focal Spot smaller than 0.6 .
