HF Series Generators
T roubleshooting
TR-1005R4
27
SECTION 4 ERROR CODES
ERROR CODE LIST
ERROR CODE DESCRIPTION
“------------” SYSTEM FAILURE. FATAL ERROR.
E01
FAILURE IN POWER UP ROUTINE.
NO COMMUNICATION BETWEEN HT CONTROLLER BOARD AND ATP CONSOLE CPU BOARD.
E02
FAILURE IN POWER UP ROUTINE. RAD GENERATOR CONFIGURED AS R&F GENERATOR.
NO COMMUNICATION BETWEEN ATP CONSOLE CPU BOARD AND FLUORO CPU BOARD.
E03 FAILURE IN POWER UP ROUTINE. ALL WORKSTATIONS ARE UNCONFIGURED.
E04 “PREP” SIGNAL RECEIVED WITHOUT CONSOLE ORDER.
E05 “FLUORO” SIGNAL ACTIVE WITHOUT REQUEST.
E06 “PREP” OR/AND “EXPOSURE” ORDERS ACTIVATED DURING POWER UP ROUTINE.
E07 WRONG DATA FOR X-RAY TUBE-2.
E08 WRONG DATA FOR X-RAY TUBE-1.
E09 GENERATOR OVERLOAD. ARCING OR IGBT FAULT.
E10
EEPROM CORRUPTED OR NO INITIALIZED IN ATP CONSOLE CPU BOARD OR IN HT CONTROLLER
BOARD. WRONG DATA CALIBRATION.
E11 NO VOLTAGE IN CAPACITOR BANK.
E12 NO mA DURING EXPOSURE OR mA OUT OF TOLERANCE. WRONG FILAMENT CURRENT.
E13 NO kVp DURING EXPOSURE OR k Vp OUT OF TOLERANCE.
E14 EXPOSURE SIGNAL WITHOUT X-RAY EXPOSURE CONSOLE COMMAND.
E15 NO CURRENT ON FILAMENT. WRONG SELECTION OF FOCAL SPOT DETECTED DURING “PREP”.
E16 INVALID VALUE OF: kVp, mA OR kW.
E17 COMMUNICATION ERROR BETWEEN ATP CONSOLE CPU BOARD AND HT CONTROLLER BOARD.
E18 ROTOR RUNNING WITHOUT ORDER OR ROTOR ERROR.
E19 mA DETECTED WITHOUT “EXPOSURE” ORDER.
E20 kVp DETECTED WITHOUT “EXPOSURE” ORDER.
E21 WRONG TUBE-1 SELECTION.
E22 WRONG TUBE-2 SELECTION.
E23 CALIBRATION DATA NOT STORED.
E24 THE BUCKY HAS NOT BEEN DETECTED TO BE MOVING.
E25 BATTERY FAILURE IN BATTERY POWERED GENERATORS.
E26 VOLTAGE FAILURE IN BATTERY POWERED GENERATORS WITH STAND-ALONE.
E27 FAILURE IN CONSOLE EPROM. BAD CHECKSUM.
