HF Series Generators
Configuration
CF-1018R3
21
2.3 LIMIT OF MAXIMUM kW
The Maximum kW of the Generator is factory set according to the Generator
performance. Generator kW can be limited to a lower value.
This limit can be set to a lower value to match the maximum
Generator power to the Line power, due to a high line impedance
(refer to Pre-installation document).
1. Enter in c alibration mode by pressing the “Manual Calibration” button on
the GSM program. Select any workstation (WS) and press the “OK”
button.
2. Select the E07 Memory Location (memory location is shown on the mA
Display).
3. Set the new limit of Maximum kW by pressing the “Increase” or
“Decrease” calibration buttons and store the value by pressing the
“Store” button.
4. Exit from calibration mode.
Record configuration data for E07 in the Data Book.
Note .
Note .
