HF Series Generators
Configuration
CF-1018R3
1
SECTION 1 INITIAL CONFIGURATION PROCEDURE
Configuration provides the initial settings for extended memory and checkout
procedures that must be carried out before making X-ray exposures.
Functional characteristics of this Generator are defined at the time of
installation.
Calibration and some configuration data are stored in a non-volatile memory
chip (U3-EEPROM) located on the HT Controller Board in the Power Cabinet.
When the initial setup and checkout has been completed the Generator will be
ready for Calibration.
Record all the configuration settings in the Data Book.
DO NOT SUPPLY THE MAIN POWER UNTIL SPECIFICALLY
INSTRUCTED TO DO SO IN THIS DOCUMENT.
THE MAIN CAPACITORS OF THE HIGH VOLTAGE INVERTER
RETAIN A LARGE PORTION OF THEIR CHARGE FOR
APPROX. 3 MINUTES AFTER THE UNIT IS TURNED OFF.
The Generator configuration is determined by:
• X-ray tube(s) number, model and use.
• System requirements (Bucky, Tomo, AEC, ...)
• Maximum kV, kW.
Specific versions of U24-EPROM on the ATP Console CPU Board and U5 on
the HT Controller Board are based on the Generator configuration. (Refer to
Illustration 1 -1).
The system configuration and test switches are:
DIP SWITCH LOCATION FUNCTION
3024SW1 - ATP Console CPU Board System Configuration
3024SW2 - ATP Console CPU Board Tes t
3024SW3 - ATP Console CPU Board No used for Configuration
3000SW2 - HT Controller Board System Configuration and Test
Note .
