HF Series Generators
Calibration
CA-1036R2
2
1.1 GENERATOR SPECIFICATIONS
1.1.1 MINIMUM CURRENT TIME PRODUCT (mAs)
• Minimum Current Time Product obtained at 0.1 s is 1 mAs.
• Minimum Current Time Product within the specified r anges of
compliance for linearity and constancy is 0.1 mAs.
1.1.2 ACCURACY OF RADIOGRAPHIC AND FLUOROSCOPIC PARAMETERS
Specified accuracy does not include test equipment accuracy.
PARAMETERS
ACCURACY
(with 12 BITS HT Controller)
kV
±(3%+1kV)
RAD
mA
±(4%+1mA)
Exposure Time
±(2%+0.1ms)
kV
±(3%+1kV)
FLUORO
mA
± 10%
Exposure Time
±(1%+20ms)
1.1.3 HV FREQUENCY
The operating HV Frequency of this Generator is 25 kHz / 30 kHz.
1.1.4 DUTY CYCLE
The Generator duty cycle is continuous, but limits should be set during
installation depending on the capacity of the X-ray tube.
Note .
