Sedecal SHF-310 - AEC Configuration

HF Series Generators
Configuration
CF-1018R3
6
1.3 AEC CONFIGURATION
Configure the following Jumpers on the “AEC Control Board” (located over the
“ATP Console CPU Board”) and on the “AEC Adaptation Board” when this
option is installed in the Generator Cabinet.
AEC CONTROL BOARD (A3012--01/02/05)
JUMPER DESCRIPTION
JP1 A FOR TV CAMERA
B FOR PHOTOMULTIPLIER
C FOURTH ION CHAMBER & ATS--DIG
A
3
0
1
2
0
5
:
J
P
1
C
J
P
2
A
A
N
D
J
P
4
B
F
O
R
F
O
U
R
T
H
I
O
N
C
H
A
M
B
E
R
&
A
T
S
D
I
G
JP2 A FOR TV CAMERA
B FOR PHOTOMULTIPLIER
A
3012-05: JP1-C, JP2-
A
A
ND JP4-B FOR FOURTH ION CH
A
MBER &
A
TS--DIG
A3012-02: JP1-A, JP2-A AND JP4-A FOR ABC WITH TV CAMERA
A3012-01: JP1-B, JP2-B AND JP4-A FOR ABC WITH PHOTOMULTIPLIER
JP4 A FOR PHOTOMULTIPLIER -- AEC
B FOR ION CHAMBER -- AEC & ATS--DIG
,
JP3 A FOR HIGH SENSITIVITY
B FOR LOW SENSITIVITY
JP3-A FOR AEC WHEN USING ION CHAMBER WITH HIGH SENSITIVITY
JP3-B FOR AEC WHEN USING ION CHAMBER WITH LOW SENSITIVITY
NOTE: HIGH SENSITIVITY IS > 2 V / mR (> 0.223 V / μGy) (a.e. Vacutec Ion Chamber)
LOW SENSITIVITY IS < 2 V / mR (< 0.223 V / μGy) (refer to Ion Chamber documentation)
AEC CONTROL BOARD (A3012--06/07/09)
JUMPER DESCRIPTION
JP1 A FOR TV CAMERA
B FOR PHOTOMULTIPLIER
C EXTERNAL kV CONTROL
JP1-A FOR ABC WITH TV CAMERA
JP1-B FOR ABC WITH PHOTOMULTIPLIER
JP1-C FOR ABC WITH EXTERNAL kV UP & DOWN CONTROL
JP2 A FOR HIGH SENSITIVITY
B FOR LOW SENSITIVITY
JP2-A FOR AEC WHEN USING ION CHAMBER WITH HIGH SENSITIVITY
JP2-B FOR AEC WHEN USING ION CHAMBER WITH LOW SENSITIVITY
JP3 B FOR NORMAL OPERATION JP3-B FOR NORMAL OPERATION
JP4 A FOR NORMAL OPERATION JP4-A FOR NORMAL OPERATION (Only in A3012-06)
NOTE: HIGH SENSITIVITY IS > 2 V / mR (> 0.223 V / μGy) (a.e. Vacutec Ion Chamber)
LOW SENSITIVITY IS < 2 V / mR (< 0.223 V / μGy) (refer to Ion Chamber documentation)
