Sedecal SHF-310 - Configuration and Test Switches; 3024 SW1 - ATP Console CPU Board; 3024 SW2 - ATP Console CPU Board

HF Series Generators
Configuration
CF-1018R3
3
1.1 CONFIGURATION AND TEST SWITCHES
ATP Console Dip Switches must be configured with the Generator turned OFF,
and they are read when the Generator is turned ON again.
1.1.1 3024SW1 - ATP CONSOLE CPU BOARD
Set dip switch 3024SW1 in accordance with the Table 1-1.
Table 1-1
System Configuration Dip Switch 3024SW1 on the ATP Console CPU Board
3024SW1 POSITION OPEN (OFF) CLOSED (ON)
1 60 Hz
*1)
50 Hz
*1)
2 --
Normal -- Application mode.
Exposures are inhibited when
Door Interlock Switch is opened.
3 Not used. Set i n “OFF” position. Not used.
4 Not used. Set i n “OFF” position. Not used.
Note.-- *1) This switch is related with the frequency of the Rotor Controller. For Generators with High Speed Starter
(LV-DRAC) or Generators Powered through Batteries with Stand-Alone set always SW1-1 to 60 Hz, in the rest of
Generators set SW1-1 in accordance with the Power Line Frequency.
1.1.2 3024SW2 - ATP CONSOLE CPU BOARD
Set dip switch 3024SW2 verifying that each position is set as Table 1-2.
Table 1-2
Test Dip Switch 3024SW2 on the ATP Console CPU Board
3024SW2 POSITION OPEN (OFF) CLOSED (ON)
1
Skips reception with the HT Controller. Use only
for display purposes, troubleshooting or Demo
Consoles when there is no Power Module. Be
sure that J3 connector is not plugged to the ATP
Console CPU Board.
Normal -- Application mode.
2
Tick Sound (button / command acknowledge) is
not emitted by the ATP Console CPU Board.
Tick Sound (button / command acknowledge) is
emitted by the ATP Console CPU Board.
3 Normal -- Application mode. Service Mode .
4
kV Log (Renard) Scale Mode for kV variation
(kV changes in logarithmic steps) (if available).
kV Lineal Scale Mode for kV variation (Normal
mode) (kV changes one by one).
