SECTION 2 PRE-INSTALLATION DATA
This section provides product information and illustrations showing physical
dimensions, weight, mounting holes and normal access areas for cabling and
service. (Refer to Illustration 2-1.)
PHYSICAL CHARACTERISTICS
C
O
M
P
O
N
E
N
T
DIMENSIONS
W
E
I
G
H
T
COMPONENT
Length Width Height
WEIGHT
LINE POWERED GENERATORS
Vertical Generator Cabinet
with LF-RAC (LSS) or DRAC (HSS)
506 mm 468 mm 1101 mm 148 kg
Compact Generator Cabinet
(for only 1 Tube (LSS))
445 mm 360 mm 568 mm 72 kg
Compact Generator Cabinet
(for 1 or 2 Tubes (LSS or HSS))
592 mm 360 mm 690 mm 95 kg
CAPACITOR ASSISTED GENERATORS
Compact Generator Cabinet
with Capacitors Module
500 mm 360 mm 790 mm 108 kg
BATTERY POWERED GENERATORS
Compact--ESM Generator Cabinet
with Batteries Module
813 mm 436 mm 948 mm 235 kg
Compact--ESM Generator Cabinet
with Batteries Module (17 A/h batteries)
813 mm 436 mm 1223 mm 372 kg
