3.3 LINE POWERED GENERATORS -- POWER LINE REQUIREMENTS
• Operation:
GENERATOR MODEL SHF-310 SHF-315 SHF-320 SHF-325 SHF-330 SHF-335
Max. Power kW 32 kW
Maximum mA 400 mA
Maximum kVp 125 kVp 150 kVp 125 kVp 150 kVp 125 kVp 150 kVp
Power Line A A B B C/D C/D
GENERATOR MODEL SHF-410 SHF-415 SHF-420 SHF-425 SHF-430 SHF-435
Max. Power kW 40 kW
Maximum mA 500 mA
Maximum kVp 125 kVp 150 kVp 125 kVp 150 kVp 125 kVp 150 kVp
Power Line A A B B C/D C/D
GENERATOR MODEL SHF-510 SHF-515 SHF-520 SHF-525 SHF-530 SHF-535
Maximum Power kW 50 kW
Maximum mA 640 mA (or 630 mA under special order)
Maximum kVp 125 kVp 150 kVp 125 kVp 150 kVp 125 kVp 150 kVp
Power Line A A B B C/D C/D
GENERATOR MODEL SHF-630 SHF-635 SHF-835
Maximum Power kW 64 kW (or 65 kW under special order) 80 kW
Maximum mA 640 mA (or 650 mA under special order) 800 mA (or 1000 mA under special order)
Maximum kVp 125 kVp 150 kVp 150 kVp
Power Line C/D C/D D (or E for 1000 mA)
POWER LINE
A B C D E
230 / 240 VAC,
Single-Phase, 50 / 60 Hz
230 / 240 VAC,
Three-Phase, 50 / 60 Hz
400 / 415 / 440 VAC,
Three-Phase, 50 / 60 Hz
480 VAC,
Three-Phase, 50 / 60 Hz
530 VAC,
Three-Phase, 50 / 60 Hz
Line voltage automatic compensation: ±10%.
Maximum line regulation for maximum kVA demand: 5%.
NOTES: -- For lines at 210 VAC or below an auxiliary boost transform er is required to adequate the line voltage to the Generator input.
-- For 80 kW Generators operating with lines at 400 / 415 / 440 VAC an auxiliary boost transformer is required to adequate
the line voltage to 480 VAC (or 530 VAC).
