3.5 CAPACITOR ASSISTED GENERATORS -- POWER LINE REQUIREMENTS
• Operation:
G Single-Phase at 100 / 110 / 120 / 208 / 230 / 240 VAC.
G Line voltage automatic compensation: ±10%.
G 50 Hz / 60 Hz.
• Thermomagnetic Interruptor / Circuit Breaker rating should be:
G 8 / 10 / 12.5 / 16 / 20 A (1P+N).
• Differential Sensitivity: 30 mA
• Minimum kW required: 2.0 kW
• Line Impedance should comply with Standard IEC-60601.2.7.
3.6 CAPACITOR ASSISTED GENERATORS -- RECOMMENDED WIRE SIZE
The minimum recommended wire size for the line voltage is:
LINE VOLTAGE WIRE SIZE
100 / 110 VAC 4mm
2
AWG 12
208 / 230 / 240 VAC 2.5 mm
2
AWG 14
