HF Series Generators
Pre-Installation
PI-1005R3
16
Table 3-1 (cont.)
Minimum Wire Size from Distribution Transformer to Room Electrical Cabinet
G
E
N
E
R
A
T
O
R
LINE
WIRE SECTION AT:
GENERATOR
L
I
N
E
VOLTAGE
15 m 30 m 45 m 60 m
208 VAC *
83 mm
2
AWG 3/0 120 mm
2
AWG 4/0 -- -- -- --
50 kW, 1φ
230 VAC 83 mm
2
AWG 3/0 120 mm
2
AWG 4/0 -- -- -- --
,
φ
240 VAC 83 mm
2
AWG 3/0 120 mm
2
AWG 4/0 -- -- -- --
208 VAC *
50 mm
2
AWG 1/0 95 mm
2
AWG 3/0 120 mm
2
AWG 4/0 -- --
230 VAC 50 mm
2
AWG 1/0 83 mm
2
AWG 3/0 120 mm
2
AWG 4/0 -- --
240 VAC 50 mm
2
AWG 1/0 83 mm
2
AWG 3/0 120 mm
2
AWG 4/0 -- --
50 kW, 3φ
400 VAC 25 mm
2
AWG 4 50 mm
2
AWG 1/0 70 mm
2
AWG 2/0 95 mm
2
AWG 3/0
,
φ
415 VAC 25 mm
2
AWG 4 50 mm
2
AWG 1/0 70 mm
2
AWG 2/0 95 mm
2
AWG 3/0
440 VAC 25 mm
2
AWG 4 50 mm
2
AWG 1/0 70 mm
2
AWG 2/0 83 mm
2
AWG 3/0
480 VAC 25 mm
2
AWG 4 50 mm
2
AWG 1/0 70 mm
2
AWG 2/0 83 mm
2
AWG 3/0
400 VAC 35 mm
2
AWG 2 70 mm
2
AWG 2/0 95 mm
2
AWG 3/0 120 mm
2
AWG 4/0
64 kW
,
3
φ
415 VAC 35 mm
2
AWG 2 70 mm
2
AWG 2/0 83 mm
2
AWG 3/0 120 mm
2
AWG 4/0
6
4
k
W
,
3
φ
(or 65 kW, 3φ)
440 VAC 35 mm
2
AWG 2 70 mm
2
AWG 2/0 83 mm
2
AWG 3/0 105 mm
2
AWG 4/0
480 VAC 25 mm
2
AWG 4 50 mm
2
AWG 1/0 83 mm
2
AWG 3/0 105 mm
2
AWG 4/0
400 VAC 50 mm
2
AWG 1/0 83 mm
2
AWG 3/0 105 mm
2
AWG 4/0 120 mm
2
AWG 4/0
*
8
0
k
W
3
φ
415 VAC 35 mm
2
AWG 2 70 mm
2
AWG 2/0 105 mm
2
AWG 4/0 120 mm
2
AWG 4/0
*80kW, 3φ
440 VAC 35 mm
2
AWG 2 70 mm
2
AWG 2/0 105 mm
2
AWG 4/0 120 mm
2
AWG 4/0
480 VAC 35 mm
2
AWG 2 70 mm
2
AWG 2/0 95 mm
2
AWG 3/0 120 mm
2
AWG 4/0
NOTES: -- For lines at 210 VAC or below an auxiliary boost transform er is required to adequate the line voltage to the Generator input.
-- For 80 kW Generators operating with lines at 400 / 415 / 440 VAC an auxiliary boost transformer is required to adequate
the line voltage to 480 VAC (or 530 VAC).
