HF Series Generators
Configuration
CF-1018R3
19
2.2 HOW TO ENTER AND STORE DATA IN THE EXTENDED MEMORY
The Extended Memory data are entered from the Console when the unit is in
service mode. Access to memory locations as indicated below:
1. Turn the Generator OFF and set the Test dip switch 3024SW2-3 on the
ATP Console CPU Board in “On” position to permit the service mode.
2. Power ON the System and select the “Manual Calibration” button on the
GSM program.
3. Select the needed Workstation (WS) using the “Up” and “Down” buttons,
then press the “OK” button to enter in calibration mode.
In calibration mode, only the kV and mA parameters c an be
modified, values for Time and mAs are factory programmed.
4. Increase the mA value beyond the maximum mA position. The mA
Display will show the first Extended Memory location (E01), they will
continue sequentially as the “ Increase mA” button is pressed.
The values stored in each location are shown on the “ Calibration Value”
Display after pressing the “Read” button or after pres sing the “Increase”
or “Decrease” buttons of this panel. Since these buttons are also used
to increase or decrease the stored values, one number should be added
or subtracted from the reading, to obtain the current stored value.
5. Select the new value by pressing the “Increase” and “Decrease” buttons.
Each time these buttons are pressed the value displayed on the
calibration panel is increased or decreased one step.
6. Store the new value by pressing the “Store” button (Check-summ
function).
If the “ Store” button is not pressed after a new value is selected,
no modified data will be retained.
7. Exit from calibration mode by pressing the “Manual Calibration” button
again.
8. Turn the Generator OFF and set dip switch 3024SW2-3 on the ATP
Console CPU Board in “Off” position to place the Generator in normal
mode.
