HF Series Generators
T roubleshooting
TR-1005R4
11
2.5.3 EXTERNAL BACKUP OF THE APR TECHNIQUES
1. Connect a Laptop (PC) to the Touch Screen Console with a serial cable
(DB9 with female pins on both ends; on one end Pin 2 connected with
Pin 3; on the other end Pin 2 connected with Pin3; Pin 5 connected with
Pin 5). Connect the serial cable to port “COM4” of the Touch Screen
Console and any free port on the Laptop (PC).
2. On the Laptop (PC):
a. Select: “StartMenu / Programs / Accessories / Communications
/ Hyperterminal / hypertrm.exe”.
b. Once the Hyperterminal is opened on the Laptop (PC), configure
the connection. For that select on the Menu bar:
File --> Properties --> Connect using: COM *
(selected free port)
Configure --> Bits per second: 115200
Data Bits: 8
Parity: None
StopBits: 1
Flow Control: None
c. Then press “OK” and “OK”.
d. Select on the Menu bar: Transfer --> Receive File
on this window select:
Place received file in the following folder:
(choose a folder in the Laptop)
Use receiving protocol:
Xmodem
e. Let that window open without pressing “Receive”, by the moment.
3. On the Touch Screen Console:
a. Enter in “Service Mode” and press the “Software Upgrade” button.
b. Press the “Start--Windows” button on the keyboard connected to
the Touch Screen Console, then select: “Programs / accessories
/ hyperterminal / PORT4.ht”.
