Sedecal SHF-310 - Earthing Diagram

EARTHING DIAGRAM
I/F--103
NAME
DATE
DRAWING
REVISED
SHEET / OF
REV
F. GARCIA
30/06/04
A. DIAZ 30/06/04
REV DESCRIPTION ISSUED BY DATE
SEDECAL
1/1
OPERATOR CONSOLE
GENERATOR CABINET
HV TANK
ROOM
ELECTRICAL
CABINET
GND cable
GND cable
( yellow/green, AWG #10 )
( yellow/green, AWG #10 )
GND
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
PEDESTAL
(11)
(10)
(12)
(8)
(Option)
(3)
(4)
(5)
(6)
(7)
(1)
(2)
Central Ground
GND Stud
Cabinet Cover GND
Back Panel GND
Front Panel GND
Filter LF1 Cover GND
Adaptations Panel GND
Console GND (Bottom Panel)
Console Support GND
Pedestal Tube GND
Pedestal Cover GND
GND STUD
(9)
Note.-- (9) applicable only
for metallical Box Console
See Note
