Sedecal SHF-310 - Page 151

HF Series Generators
Configuration
SECTION 4 X-RAY TUBE DATA
The following table lists several common X-ray tubes and their corresponding
number. If a specific tube is not listed, tube specifications are given to enable
you chose a similar tube type. If none of the listed tubes are satisfactory, contact
your generator supplier to obtain special software.
Table 4-1
X-ray Tube Numbers
TUBE TUBE CODE
M
O
D
E
L
FOC
A
L
POWER RATINGS
K
H
U
T
U
B
E
NUMBER
T
U
B
E
C
O
D
E
(ID)
MODEL
F
O
C
A
L
SPOT
LS (kW) HS (kW)
KHU
001 139 TOSHIBA E7239X 1.0 / 2.0 22 / 45 -- 133
002 201 TOSHIBA E7240X 0.6 / 1.2 15 / 30 -- 140
003 140 TOSHIBA E7242X 0.6 / 1.5 18 / 49 -- 187
004 090 TOSHIBA E7252X 0.6 / 1.2 15 / 42 26 / 73 300
005 377 TOSHIBA E7254FX 0.6 / 1.2 25 / 66 39 / 100 400
006 274 TOSHIBA E7255FX 0.6 / 1.2 23 / 60 39 / 101 300
007 310 TOSHIBA E7843X 0.6 / 1.2 22 / 49 -- 150
008 344 TOSHIBA E7865X 0.3 / 1.0 3/40 -- 140
009 351 TOSHIBA E7100X 0.6 / 1.2 24 / 59 40 / 100 300
010 260 IAE RTM 101 HS 0.6 / 1.2 22 / 55 37 / 99 400
011 273 IAE RTM 101 HS 0.6 / 1.5 24 / 76 40 / 136 400
012 233 VARIAN RAD 8 1.0 / 2.0 25 / 47 -- 150
013 244 VARIAN RAD 14 0.6 / 1.2 16 / 44 27 / 72 300
014 161 VARIAN RAD 21 0.6 / 1.2 21 / 64 36 / 100 300
015 265 VARIAN RAD 60 0.6 / 1.2 26 / 67 39 / 100 400
016 238 VARIAN RAD 74 0.6 / 1.5 20 / 52 -- 200
017 252 VARIAN RAD 92 0.6 / 1.2 26 / 62 40 / 99 600
018 092 VARIAN A-192 0.6 / 1.2 25 / 63 40 / 96 300
019 309 VARIAN A196 0.6 / 1.0 20 / 47 32 / 72 350
020 094 VARIAN A-292 0.6 / 1.2 25 / 62 39 / 96 400
021 208 VARIAN G 292 0.6 / 1.2 25 / 63 39 / 95 600
022 051 GE-CGR MN 640 1.0 / 1.8 23 / 46 -- 150
023 064 GE MAXIRAY-75 0.6 / 1.5 12 / 37 21 / 62 300
024 062 GE MAXIRAY-100 0.6 / 1.25 18 / 55 31 / 100 350
025 261 SIEMENS DR 154/30/50 1.2 / 1.8 31 / 53 -- 200
026
027
Note .-- Power Ratings are for 60 Hz. To calculate Power Ratings for 50 Hz multiply the values by 0.91 TB47
