Sedecal SHF-310 - Page 425

HF Series Generators
Renewal Parts
RP-1024R0
8
MISCELLANEOUS
LIST OF PARTS WITHOUT ILLUSTRATION
Item Designation Qty FRU Rep Mfg. Ref. Remarks
FUSE KIT
F2 (1.5 A, 250V ) SB 1 2 N 53801012 On the Front Panel (Mod. 3)
F3, F4, F5 (50 A, 600VAC) SB 3 2 N 53801011 Input Line Fuses (Mod. 6)
F9 (0.4 A, 250V ) SB 1 2 N 53801015 On the Power Supply at the Front Panel (Mod. 3)
F6, F7, F8 (3 A, 250V) SB 3 2 N 53801003 On the Front Panel (Mod. 3)
F12, F13 ( 10 A, 250 V, T) SB 2 2 N 53801008 On Transformer T2 (Mod. 6)
F14, F15 ( 10 A, 250 V, T) SB 2 2 N 53801008 On Looks PCB (Mod. 12)
Fuses F3, F4 (15 A, 600 V) for LV-DRAC 2 2 N 53801018 On Interface DRAC PCB (Mod. 11)
Fuses F1, F2 (0.5 A, 250 V) for LV-DRAC 2 2 N 53801019 On Interface DRAC PCB (Mod. 11)
CABLES
Interface AEC Cable 1 2 N A3251--02
Ion Chamber Cable 1 2 N A3252--03
Cable Generator -- Interface Box 1 2 N A3352--01
Cable Interface Box -- PC 1 2 N A3363--01
HAND SWITCH
Hand Switch with Sub--D 1 2 N A3223--05 For PC On/Off Box
COVER
Generator Cover 1 2 N A6470--08
DOCUMENTATION
Pre-install ation Manual 1 2 N --
Service Manual 1 2 N --
