Segway®PersonalTransporteri2,x2,x2Turf PartsReplacementGuide 13‐3
Motor Removal
To remove motor:
1. MakesureSegwayPTispoweredoffand
unplugged.
2. Establishaservicea
blepowerbase
(page7‐1).
3. Re
movegearboxonsamesideofmachineas
motorthatyouwanttoremove(page8‐4).
4. Re
movepivotbaseassembly(page9‐14).
5. Re
movechassiscover(page10‐3).
6. Us
esmallflatheadscrewdriverandgently
lifttabonconnector(seeFigure13‐1)from
backofmotor
,andthencarefullypullon
bothconnectorstounseat.SeeFigure13‐2.
Figure13‐1:PryConnectorTab
Figure13‐2:Di
sconnectCUMotorHarnessfromMotor
7. UseT‐256‐lobewrenchtoremove(2)SHCS,
M5
x0.8x12,6‐lobescrewsthatattach
motortochassis.SeeFigure13‐3.
Figure13‐3:RemoveMotor
8. Pullmotorstraightoutofsideofchassis.
connectortab
Motor with Coupling
21089-00001
20536-00001
