Segway®PersonalTransporteri2,x2,x2Turf PartsReplacementGuide 9‐7
Radio Board Removal and Installation
Radio boards are electronically bound to the
serial number of the PT and must be ordered
from Segway, pre-programmed for the specific
serial number of the PT that is being serviced;
otherwise, the InfoKey will not start the unit.
To remove radio board:
1. MakesureSegwayPTispoweredoffand
unplugged.
2. Re
movethePTbatterypacks(page3‐3).
3. Re
moveconsolecover(page9‐4).
4. Re
moveEMIshieldandantenna(page9‐6).
5. Dependingupontherevision,us
ea2mmor
2.5mmwrenchtoremovethefour(4)M3x6
buttonheadcapscrewsholdingtheradio
boardtotheUIC.
DISCARD FASTENERS AFTER REMOVAL! DO NOT
REUSE!
6. Gentlypulltheradioboardupandaway
fromtheUIC.Packagetheradioboardfor
returntocustomerbecauseitcannotbe
reused.PlaceradioboardinESDbagoron
cleanESDworksurface.
Figure9‐8:RemoveorInstallRadioBoard
7. VerifythattheserialnumberofthePT
matchestheserialnumberprintedonthe
packagingforthereplacementradioboard.
Retain replacement part packaging to use as
packaging for returning original radio board to
customer (upon customer request).
To install radio board:
1. MakesureSegwayPTispoweredoffand
unpluggedwithba
tteriesremoved.
2. Ali
gnradioboardconnectorswithmating
connectorsontheUIC.Applypressurefirst
atthefrontoftheradioboardtoseatthe
connectors,thengentlypressboardinto
place.
Do not force the board into place; it should fit
easily with only light pressure.
3. Insert4M3x6fasteners(20243‐00001).Usea
2.5mmwrenchtodriveeachscrewand
torqueto0.8‐1.0N‐m.SeeFigure9‐8.
4. InstallEMIshieldan
dantenna(page9‐6).
Radio Board
19455-00002
20243-00001
