Segway®PersonalTransporteri2,x2,x2Turf PartsReplacementGuide 13‐5
Elastomer Bushing Inspection, Removal, and Installation
To inspect elastomer bushing:
Checktoseeifelastomerbushingiswornor
damaged.Presenceofexcessiveparticlesof
elastomermaterialindi catesreplacementis
necessary.SeeFigure13‐6.
Figure13‐6:InspectElastomerBushing
To remove elastomer bushing:
1. MakesureSegwayPTispoweredoffand
unplugged.
2. Pullel
astomerbushing offmotorcoupling.
Completely clean residue from drive coupling and
cavity using cotton swabs and household window
cleaner. Repeat process with isopropyl alcohol
until fully clean.
To install elastomer bushing:
1. MakesureSegwayPTispoweredoffand
unplugged.
2. Ma
kingsuretabsonelastomerbushinggo
onfirst,alignnewelastomerbushingwith
coupling,andslideonuntilseated.See
Figure13‐7.
Figure13‐7:InstallElastomerBushing
Do not remove coupling from motor. If damaged,
replace entire motor assembly.
3. Performpost‐servicetests(pageA‐1).
Elastomer Bushing
coupling
21091-00001
