Segway®PersonalTransporteri2,x2,x2Turf PartsReplacementGuide 9‐3
ConsolecomponentsareshowninFigure9‐1.
Figure9‐1:ConsoleComponents
Before Servicing the Console
AllPTmodelshavebeenmanufacturedwith
oneoftworevisionsoftheconsolehousingand
cover.Therevisionisdeterminedbythepart
numberofthehousing,whichislocatedonthe
forwardpartofthehousingandisvisibleafter
thecoverisremoved.Theconsolehousingpart
numbersforea
chrevisionareasfollows:
• FirstRevi
sion:20055‐00002
• SecondRevision:209
25‐00002
First-revision console housing cover parts are no
longer manufactured or supported. First-revision
components are not compatible with second-
revision components; similarly, second-revision
components are not backward compatible with
first-revision components. AS A RESULT, IF ANY
FIRST-REVISION CONSOLE HOUSING, GASKET,
OR COVER IS DAMAGED, THE COVER, GASKET,
HOUSING, AND TRIM MUST ALL BE REPLACED
USING THE CURRENT (SECOND) REVISION.
pivot base assembly
(21249-00001)
console housing
(20055-00002, v1)
(20925-00002, v2)
EMI filter
(20375-00002(
user interface console (UIC)
(20130-00001)
console cover
(20929-00001)
EMI shield
(20110-00001)
antenna
(20169-00001)
radio board
(19455-00002)
antenna clip
(20550-00001)
