Segway®PersonalTransporteri2,x2,x2TurfPartsReplacementGuide G‐1
Glossary
6‐lobewrench(torx)
Awrenchwithastar‐shapedheadthat
fitsthesocketofa6‐lobefastener.The
SegwayPTuses6‐lobefastenersin
places,suchasthechassis,thatshould
beaccessedonlybyaCertifiedService
Technician.
balancesensorassembly(BSA)
Thecentralmonitoringunit,foundin
thecenteroftheplatform,which
accountsforvariableterrainand
communicateswiththecontroller
boardsandthemotorstobalancethe
SegwayPT.
consoleelectronics
Seeuserinterfaceconsole(UIC).
controlunit(CU)boards
Thetwointegratedcircuitboards
locatedintheplatform.TheCUboardin
thefrontisoftenreferredtoasthe“A ” 
board,andtheboardintherearasthe
“B”board(arrowsonthechassispoint
tothefrontoftheunit).
display
Circularwindowoninfokeythatshows
machineconditionsthroughLCD
segmentsandLEDcoloredlights.
environmentalseal
Awatertightsealnecessarytoprevent
damagetotheSegwayPT.
EMI
Electromagneticinterference.
ESD
SeeElectrostaticdischarge.
Electrostaticdischarge
Therapiddischargeofaccumulated
electricalcharge.Topreventdamageto
theSegwayPT,aCertifiedService
Technicianshouldalwaysstandona
staticmatorwearagroundingheelor
wriststrapwhileworkingonelectrical
elementsoftheSegwayPT.
flange
Triangularplatewiththreewheelmounting
studsaffixedtotheendofthegearboxoutput
shaft.
harness
Agroupofcablesboundtogethertoformone
assembly,typicallywithconnectorsthatplugor
snapintoplace.
hexwrench
Ahexagonalwrenchthatfitsthesocketofahex
fastener.
IEC(InternationalElectrotechnical
Commission)connector
ThisisthelocationwheretheSegwayPTis
pluggedintocharge(chargeport).
LeanSteerframe
Comprisesallofcomponentsinthesteering
assembly(upperandlowerframe,handlebars,
heightadjustmentknob,wedges)that attachto
pivotbase.
N‐m(Newton‐meter)
Themeasurementunitfortorquingnuts,bolts,
andscrews.
rollpins
Thetwosmallcylindricalpegslocatedonthe
gearboxthatfitintoholesonthechassisand
alignthegearboxonthechassis.
RTVsiliconesealant
Asiliconesealantthatvulcanizesatroom 
temperature,andisusedinsomemodelsin
placeofagaskettosealthegearboxtothe
SegwayPTchassis.
