Segway Personal Transporter i2 User Manual

Segway®PersonalTransporteri2,x2,x2TurfPartsReplacementGuide xi
About This Guide
Purpose
Thepurposeofthisguideistoprovideinstructionsforservicingthe2
nd
Generation(“Gen2”)
SegwayPersonalTransporter(SegwayPT)modelsi2,x2,andx2Turf.
Audience
Chapters1through6ofthismanualarewrittenforeithercustomersorSegwaytrained,certified
servicetechniciansworkingunderagreementwithSegwayInc.Chapters7through14ofthis
manualarewrittenforonlySegwaytrained,certifiedservicetechniciansworkingunder
agreementwithSegwayInc.
Certification
BecomingaSegwaycertifiedtechnicianinvolvesafour‐levelcertificationprocess.Theservice
technicianmayberequiredtoundergotrainingateachlevel.Uponsatisfactorycompletionof
thistraining,theservicetechnicianbecomescertifiedtomaintaintheSegwayPTpartsand
assembliesaccordingtothefollowingscheme:
Level PartsandAssembliesCertifiedtoMaintain
Maintenance
Instructions
1
• CustomerReplaceableParts
- LeanSteerFrame
- Mats
- BatteryPacks
- Tire/WheelAssembly
- Fender
• GearboxRemoval
• Chapter1
• Chapter2
• Chapter3
• Chapter4
• Chapter5
• Chapter8
2
• Level1(sameasabove)
• PowerbaseTrim
• ServiceablePowerBase
• Console
• Sameasabove
• Chapter6
• Chapter7
• Chapter9
3
• Level1andLevel2(sameasabove)
• EmbeddedSystems
- ChassisCover
- CUBoards
- BalanceSensorAssembly(BSA)
- Motor
- PowerBaseChassis
• Sameasabove
• Chapter10
• Chapter11
• Chapter12
• Chapter13
• Chapter14
4
• Level1,Level2,andLevel3(sameasabove)
• Diagnostics(withspecialtools)
• Sameasabove
