9‐6 Segway®PersonalTransporteri2,x2,x2TurfPartsReplacement
EMI Shield Removal and Installation
Itisnecessarytoremovetheelectromagnetic
interference(EMI)shieldtogainaccesstothe
diagnosticinterfaceconnectorsontheconsole
radioboard.Whenreplacingtheuserinterface
console(UIC),thereplacementUICwillinclude
theEMIshield.Thereshouldbenoreasonto
replacetheEMIshieldalone.
To remove EMI shield:
1. MakesureSegwayPTispoweredoffand
unplugged.
2. Remov
econsolecover(page9‐4).
3. Remov
etheradio’santennabyliftingup
whiletwistinggentlyuntilitunseatsfrom
theradioboard.
4. Dependinguponrevision,usea2mmor
2.5
mmwrenchtoremovethefour(4)M3x6
buttonheadcapscrewsholdingthe
electromagneticinterference(EMI)shieldto
theUIC.SeeFigure9‐6.
Figure9‐6:RemoveorInstallEMIShield
DISCARD FASTENERS AFTER REMOVAL! DO NOT
REUSE!
5. CarefullylifttheEMIcoverupandaway
fromtheradioboardassembly.
6. Wheninstruc
tedbyDiagnosticsmanual,
connectdiagnosticequipmenttoService
HeaderAandServiceHeaderBconnectors
onconsoleradio.SeeFigure9‐7.
Figure9‐7:ConnectDiagnosticEquipmenttoConnectors
onConsoleRadio
To install EMI shield:
1. MakesureSegwayPTispoweredoffand
unplugged.
2. Disconnectdi
agnosticequipment.
3. SeatEMIshieldonUIC.Th
read(4)cap
screws(20203‐00002)throughholesinEMI
shieldtopivotbase.Using2.5mm6‐lobe
wrench,driveeachscrewandtorqueto2.6
N‐m.SeeFigure9‐6.
4. Pe
rformpost‐servicetests(pageA‐1).
EMI Shield
20110-00001
20203-00002
