Wireless InfoKey Controller Battery Removal and Installation
To remove battery:
1. MakesureSegwayPTispoweredoffand
unplugged.
2. Rot
ateWirelessInfoKeycontroller45
degreescounterclockwiseandseparatefrom
dockadapterring.SeeFigure1‐12.
Figure1‐12:RemoveorReplaceWirelessInfoKey
ControlleronDockAdapterRing
3. Usingacoinoraflatheadscrewdriver,
unscrewbackcoverofWirelessInfoKey
controllerandremovebattery.
SeeFigure1‐13.
Figure1‐13:RemoveorInstallWirelessInfoKeyController
Battery
To install battery:
1. MakesureSegwayPTispoweredoffand
unplugged.
2. Ve
rifythatnewbatteryistypeCR2430,
availableaspartofSegwayInfoKeykit
(21064‐00001).
3. InsertWi
relessInfoKey controllerbattery
withpositive(+)sideshowing.See
Figure1‐13.
4. Rea
ttachtheWirelessInfoKeycontroller’s
backcoverusingacoinorflathead
screwdriver.
5. PlaceWi
relessInfoKeycontrollerondock
adapterringandrotateclockwiseuntilthe
WirelessInfoKeycontrollerislockedinto
position.(Anaudibleclickshouldbe
detected.)SeeFigure1‐12.
6. Pe
rformpost‐servicetests(pageA‐1).
