Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
9
Error and alarm messages
Diagnostics
Fatal error code F3203/3204, error 108, subcode 004/005
Error message Incorrect reference voltage.
Cause • Incorrect reference voltage
• Incorrect supply voltage of the DCS..B option
• Faulty component on the DCS..B option
Remedy • Check supply voltage of DCS..B option
• Switch DCS..B option off and on again
Fatal error code F3205/3206, error 108, subcode 006/007
Error message Faulty system voltage.
Cause • Faulty supply voltage of the DCS..B option
• Faulty component on the DCS..B option
Remedy • Check supply voltage of DCS..B option
• Switch DCS..B option off and on again
Fatal error code F3207/3208, error 108, subcode 008/009
Error message Incorrect test voltage.
Cause • Incorrect test voltage
• Faulty supply voltage of the DCS..B option
• Faulty component on the DCS..B option
Remedy • Check supply voltage of DCS..B option
• Switch DCS..B option off and on again
Fatal error code F3210, error 108, subcode 010
Error message Incorrect supply voltage.
Cause • Incorrect DC 24 V supply of the DCS..B option
• Faulty component on the DCS..B option
Remedy • Check the supply voltage of the unit
• Switch DCS..B option off and on again
Fatal error code F3214, error 108, subcode 011
Error message Ambient temperature of the unit is not in the defined range.
Cause • Ambient temperature not within specified range
• Faulty component on the DCS..B option
Remedy • Check the ambient temperature
• Switch DCS..B option off and on again
Fatal error code F3306, error 108, subcode 012
Error message Plausibility check for position changeover.
Cause Position changeover during ZSC, JSS or DMC is permanently activated.
Remedy • Check ZSC activation
• Check JSS activation
• Check DMC activation (only for monitoring via position)
Fatal error code F3601/3602, error 108, subcode 056/057
Error message Faulty watchdog test.
Remedy Replace the DCS..B option and send it together with error number to SEW Service for
further inspection.
