Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
115
9
Error and alarm messages
Diagnostics
Fatal error code F3603, error 108, subcode 013
Error message Faulty switching of the LOSIDE driver DO2_M.
Cause Short-circuit of digital output DO2_M (X83:2).
Remedy Check wiring at the digital output.
Fatal error code F3604, error 108, subcode 014
Error message Faulty switching of the HISIDE driver DO2_P.
Cause Short-circuit of digital output DO2_P (X83:1).
Remedy Check wiring at the digital output.
Fatal error code F3605, error 108, subcode 015
Error message Faulty switching of the LOSIDE driver DO0_M.
Cause Short-circuit of digital output DO0_M (X82:2).
Remedy Check wiring at the digital output.
Fatal error code F3606, error 108, subcode 016
Error message Faulty switching of the HISIDE driver DO0_P.
Cause Short-circuit of digital output DO0_P (X82:1).
Remedy Check wiring at the digital output.
Fatal error code F3607, error 108, subcode 017
Error message Faulty switching of the LOSIDE driver DO1_M.
Cause Short-circuit of digital output DO1_M (X82:4).
Remedy Check wiring at the digital output.
Fatal error code F3608, error 108, subcode 018
Error message Faulty switching of the HISIDE driver DO1_P.
Cause Short-circuit of digital output DO1_P (X82:3).
Remedy Check wiring at the digital output.
Fatal error code F3701/3702, error 108, subcode 058/059
Error message Faulty process data.
Remedy Replace the DCS..B option and send it together with error number to SEW Service for
further inspection.
Fatal error code F6803/6804, error 108, subcode 062/063
Error message Internal processing error in user program.
Remedy Replace the DCS..B option and send it together with error number to SEW Service for
further inspection.
