Shinko PCB1 - Page 113

- 113 -
Output
Control
output
OUT1
Relay contact
1a
Control capacity: 3 A 250 V AC (resistive load)
1 A 250 V AC (inductive load cosφ=0.4)
Electrical life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
Non-contact
voltage
(for SSR drive)
12 V DC 15%
Max. 40 mA (short circuit protected)
Direct current 4 - 20 mA DC (Resolution: 12000)
Load resistance: Max. 550
Event output EV1
Relay contact
1a
Control capacity: 3 A 250 V AC (resistive load)
1 A 250 V AC (inductive load cos =0.4)
Electrical life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
Event output EV2
[EV2, EV3(DR) options]
Relay contact
1a
Control capacity: 3 A 250 V AC (resistive load)
1 A 250 V AC (inductive load cos =0.4)
Electrical life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
Event output EV3
(EV3D , EI options)
Relay contact
1a
Control capacity: 3 A 250 V AC (resistive load)
1 A 250 V AC (inductive load cos =0.4)
Electrical life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
Control output OUT2
(EV2, EV3D options)
Relay contact 1a
[EV2, EV3(DR) options]
Control capacity: 3 A 250 V AC (resistive load)
1 A 250 V AC (inductive load cos =0.4)
Electrical life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
Non-contact voltage
(for SSR drive)
(DS, EV3DS options)
12 V DC 15 %
Max. 40 mA (short circuit protected)
Direct current
(DA, EV3DA options)
4 – 20 mA DC (Resolution: 12000)
Load resistance: Max. 600
Transmission output
(EIT option)
Resolution 12000
Output
4 – 20 mA DC (Load resistance: Max. 550 )
Output
accuracy
Within 0.3% of Transmission output span
Response time 400 ms + Input sampling period (0%→90%)
Insulated power output
(P24 option) Output voltage 24 3 V DC (when load current is 30 mA DC)
Ripple voltage Within 200 mV DC (when load current is 30 mA DC)
Max. load
current
30 mA DC
