- 118 -
PTN/STEP
Display
Indicates the pattern number or step number.
Each time the DISP key is pressed, the PTN/STEP Display and the
PTN/STEP indicator alternately indicate the pattern number and step
number.
Flashes during Wait action, or when the step number is indicated.
If ‘SV digital reception’ is selected in [Communication protocol],
r is indicated.
7-segments Orange LED display 1.5-digits
Character size:14.0 x 7.0 mm (H x W)
Indicator PTN indicator
Lights up when the pattern number is indicated on the PTN/STEP
Display.
Orange LED
STEP indicator Lights up when the step number is indicated on the PTN/STEP Display.
Orange LED
PTN/STEP
indicator
LED for the pattern number or step number lights up.
Each time the DISP key is pressed, the PTN/STEP indicator and the
PTN/STEP Display alternately indicate the pattern number and step
number.
Green LED 12 pieces (PTN, STEP, 1 to 10)
Action
indicator
OUT (Green)
Lights up when control output OUT1 is ON.
Lights up when Heating output [DS, DA, EV2 (if /020 is selected in
Event output EV2 allocation), EV3D options] is ON.
For direct current output type, flashes corresponding to the MV in 125
ms cycles.
RUN (Orange)
Lights up
during
p
rogram control RUN.
Flashes during Program control HOLD or Fixed value control.
EV1 (Red) Lights up when Event output EV1 is ON.
EV2 (Red)
Lights up when Event output EV2 [(EV2, EV3(DR) options] is ON.
Lights up when control output OUT2 [Cooling output: DS, DA, EV2 (if
/020 is selected in Event output EV2 allocation), EV3D options] is
ON.
For direct current output type (DA, EV3DA options), flashes
corresponding to the MV in 125 ms cycles.
EV3 (Red)
Lights up when Event output EV3 (EV3D□, EI options) is ON.
AT (Orange)
Flashes while AT is performing.
T/R (Orange)
Lights up during serial communication (C5W, C5 options)
TX (transmitting) output.
