Recommended Environment
Ambient temperature
-10 to 55 (However, non-condensing or no icing)
Ambient humidity 35 to 85 %RH (However, non-condensing)
Environmental
specification
RoHS directive compliant
Performance
Base accuracy
At ambient temperature 23 (for a single unit mounting)
Thermocouple Within 0.2% of each input span 1 digit
However, R, S input, 0 to 200 (32 to 392 ): Within 6 (12 )
B input, 0 to 300 (32 to 572 ): Accuracy is not guaranteed.
K, J, E, T, N input, Less than 0 (32 ): Within 0.4% of input span
1 digit
RTD Within 0.1% of each input span 1 digit
Direct current,
DC voltage
Within 0.2% of each input span 1 digit
Effect of ambient
temperature
Within 50 ppm/ of each input span
Input sampling period 125 ms
Time indication accuracy Within 0.5% of setting time
Setting
resolution
Temperature Thermocouple, RTD input without decimal point: 1 ( )
Thermocouple, RTD input with decimal point: 0.1 ( )
DC voltage, current input: 1
Time 1 minute or 1 second
General Structure
Weight Approx. 220 g
External dimensions 96 x 96 x 68 (W x H x D) (Depth of control panel interior: 60 mm)
Mounting Flush (Applicable panel thickness: 1 to 7 mm)
Case Flame-resistant resin, Color: Black
Front panel Membrane sheet
Drip-proof/Dust-proof IP66 for front panel only
Display PV Display Indicates process variable (PV) in RUN mode.
Indicates setting characters in setting mode.
Flashes during Wait action or Program control Hold in program control.
7-segments Red LED display 4.5 digits
Character size: 24.0 x 11.0 mm (H x W)
SV Display Indicates desired value (SV), Output manipulated variable (MV), or
Remaining time (TIME) in RUN mode.
Retains display indication at power OFF.
Indicates the set values in setting mode.
7-segments Green LED display 4.5 digits
Character size:14.0 x 7.0 mm (H x W)
