Shinko PCB1 - Page 141

- 141 -
Characters,
Factory Default
Setting Item, Setting Range Data
p_b/
1 //10
OUT2 proportional band
Setting range:
Thermocouple, RTD input without decimal point: 0 to Input span ( )
Thermocouple, RTD input with decimal point: 0.0 to Input span ( )
DC voltage, current inputs: 0.0 to 1000.0%
Available when EV2 option {/020 (Heating/Cooling control output) is selected in
[Event output EV2 allocation]} is ordered, or when DS, DA or EV3D option is
ordered.
c_b/
/ ///3
OUT2 proportional cycle
Setting range: 0.5, 1 to 120 seconds
Available when EV2 option {/020 (Heating/Cooling control output) is selected in
[Event output EV2 allocation]} is ordered, or when DS, EV3(DR), EV3DS option is
ordered.
hysb
/ //1.0
OUT2 ON/OFF hysteresis
Setting range: 0.1 to 1000.0 ( )
DC voltage, current inputs: 1 to 10000 (The placement of the decimal
point follows the selection.)
Available when EV2 option {/020 (Heating/Cooling control output) is selected in
[Event output EV2 allocation]} is ordered, or when DS, DA or EV3D option is
ordered.
olhb
/ /100
OUT2 high limit
Setting range: OUT2 low limit value to 100%
Direct current output type (DA, EV3DA options):
OUT2 low limit value to 105%
Available when EV2 option {/020 (Heating/Cooling control output) is selected in
[Event output EV2 allocation]} is ordered, or when DS, DA or EV3D option is
ordered.
ollb
/ ///0
OUT2 low limit
Setting range: 0% to OUT2 high limit value
Direct current output type (DA, EV3DA options):
-5% to OUT2 high limit value
Available when EV2 option {/020 (Heating/Cooling control output) is selected in
[Event output EV2 allocation]} is ordered, or when DS, DA or EV3D option is
ordered.
db//
/ //0.0
Overlap/Dead band
Setting range: -200.0 to 200.0 ( )
DC voltage, current inputs: -2000 to 2000 (The placement of the
decimal point follows the selection.)
Available when EV2 option {/020 (Heating/Cooling control output) is selected in
[Event output EV2 allocation]} is ordered, or when DS, DA or EV3D option is
ordered.
cont
/ heat
Direct/Reverse action
heat Reverse (Heating) action
cool Direct (Cooling) action
