- 151 -
Characters,
Factory Default
Setting Item, Setting Range Data
a3za
/ no//
EV3 alarm value 0 Enabled/Disabled
no// Disabled
yes/ Enabled
Available when any alarm from /0 01 (High limit alarm) to /012 (High/Low limits
with standby independent alarm) is selected in [Event output EV3 allocation] -
excluding /007 (Process high alarm) and /008 (Process low alarm].
a3hy
/ //1.0
EV3 alarm hysteresis
Setting range: 0.1 to 1000.0 ( ),
DC voltage, current inputs: 1 to 10000 (The placement of the
decimal point follows the selection.)
Available when any alarm from /001 (High limit alarm) to /012 (High/Low limits
with standby independent alarm) is selected in [Event output EV3 allocation].
a3dy
/ ///0
EV3 alarm delay time
Setting range: 0 to 10000 seconds
Available when any alarm from /001 (High limit alarm) to /012 (High/Low
limits with standby independent alarm) is selected in [Event output EV3 allocation].
a3lm
/ noml
EV3 alarm Energized/De-energized
noml Energized
revs De-energized
Available when any alarm from /001 (High limit alarm) to /012 (High/Low limits
with standby independent alarm) is selected in [Event output EV3 allocation].
evi1
/ /000
Event input DI1 allocation
Event input function
Input ON
(Closed)
Input OFF
(Open)
/000 No event
/001 Pattern number selection
/002 Direct/Reverse action Direct action Reverse action
/003 Program control
RUN/STOP
RUN STOP
/004
Program control
Holding/Not holding
Holding Not holding
/005 Program control
Advance function
Advance
function
Usual control
Available when C5W, EIW, EIT, C5 or EI option is ordered.
