Characters,
Factory Default
Setting Item, Setting Range Data
evi2
/ /000
Event input DI2 allocation
Event input function
Input ON
(Closed)
Input OFF
(Open)
/000 No event
/001 Pattern number selection
/002 Direct/Reverse action Direct action Reverse action
/003 Program control
RUN/STOP
RUN STOP
/004
Program control
Holding/Not holding
Holding Not holding
/005 Program control
Advance function
Advance
function
Usual control
Available when C5W, EIW, EIT, C5 or EI option is ordered.
tros
/ pv//
Transmission output type
pv// PV transmission
sv// SV transmission
mv// MV transmission
Available when EIT option is ordered.
trlh
/ 1370
Transmission output high limit
Setting range:
PV, SV transmission: Transmission output low limit to Input range high
limit
Direct current, voltage inputs: -2000 to 10000 (The placement of the
decimal point follows the selection.)
MV transmission: Transmission output low limit to 105.0%
Available when EIT option is ordered.
trll
/ -200
Transmission output low limit
Setting range:
PV, SV transmission: Input range low limit to Transmission output high
limit
Direct current, voltage inputs: -2000 to 10000 (The placement of the
decimal point follows the selection.)
MV transmission: -5.0% to Transmission output high limit
Available when EIT option is ordered.
m_s/
/ min/
Step time unit
min/ Hours : Minutes
sec/ Minutes : Seconds
