- 42 -
RUN key (1 sec)
AT Perform
Test operation
RUN
//25
1 ////
Select a pattern number to perform.
Press the PTN key to select a
pattern.
Turn the load power ON, and press the
RUN key for test operation.
//25
1 //25
PTN/STEP
indicator
1
lights up.
Test operation starts (Program control
RUN).
(e.g.) Perform AT at Step 2 as its step
SV is constant.
Press the RUN key for approx. 1 sec.
RUN key
/500
1 /500
PTN/STEP
indicator 2 lights up.
Moves to Step 2.
+ MODE key
at//
1 ----
PTN/STEP
indicator 2 lights up.
AT Perform/Cancel
or
key
at//
1 at//
PTN/STEP
indicator 2 lights up.
AT Perform
RST key
/500
1 /500
PTN/STEP
indicator 2 lights up.
RUN mode
During AT Perform, the AT indicator
flashes. After AT is finished, the AT
indicator turns off.
As PID block 3 is selected for Step 4,
perform AT for Step 4.
RUN mode
//25
1 ////
Program control END
Returns to RUN mode [Program
control STOP (in Standby)].
RUN key
//25
1 //25
PTN/STEP
indicator 1 lights up.
Program control starts (Program
control RUN).
