Characters,
Factory Default
Setting Item, Function, Setting Range
time
1 00:00
PTN/STEP
indicator 2
lights up.
Step 2 time
• Sets Step 2 time.
Step time is the processing time of the step.
• Setting range:
----, 00:00 to 99.59 (Time unit follows the selection in [Step time unit].)
If the key is pressed at 00:00,
----
will appear.
If
----
is set, Fixed value control will be performed using Step 2 SV.
_pid
1 ///1
PTN/STEP
indicator 2
lights up.
Step 2 PID block number
• Selects PID block number used for Step 2.
• Selection item:
1 to 10
temp
1 ///0
PTN/STEP
indicator 3
lights up.
Step 3 SV
• Sets Step 3 SV.
Step SV is a value (SV) at the end of the step.
• Setting range:
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 3
lights up.
Step 3 time
• Sets Step 3 time.
Step time is the processing time of the step.
• Setting range:
----, 00:00 to 99.59 (Time unit follows the selection in [Step time unit].)
If the key is pressed at 00:00, ---- will appear.
If ---- is set, Fixed value control will be performed using Step 3 SV.
_pid
1 ///1
PTN/STEP
indicator 3
lights up.
Step 3 PID block number
• Selects PID block number used for Step 3.
• Selection item:
1 to 10
temp
1 ///0
PTN/STEP
indicator 4
lights up.
Step 4 SV
• Sets Step 4 SV.
Step SV is a value (SV) at the end of the step.
• Setting range:
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 4
lights up.
Step 4 time
• Sets Step 4 time.
Step time is the processing time of the step.
• Setting range:
----, 00:00 to 99.59 (Time unit follows the selection in [Step time unit].)
If the key is pressed at 00:00, ---- will appear.
If ---- is set, Fixed value control will be performed using Step 4 SV.
