- 45 -
Characters,
Factory Default
Setting Item, Function, Setting Range
_pid
1 ///1
PTN/STEP
indicator 4
lights up.
Step 4 PID block number
• Selects PID block number used for Step 4.
• Selection item:
1 to 10
temp
1 ///0
PTN/STEP
indicator 5
lights up.
Step 5 SV
• Sets Step 5 SV.
Step SV is a value (SV) at the end of the step.
• Setting range:
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 5
lights up.
Step 5 time
• Sets Step 5 time.
Step time is the processing time of the step.
• Setting range:
----, 00:00 to 99.59 (Time unit follows the selection in [Step time unit].)
If the key is pressed at 00:00, ---- will appear.
If ---- is set, Fixed value control will be performed using Step 5 SV.
_pid
1 ///1
PTN/STEP
indicator 5
lights up.
Step 5 PID block number
• Selects PID block number used for Step 5.
• Selection item:
1 to 10
temp
1 ///0
PTN/STEP
indicator 6
lights up.
Step 6 SV
• Sets Step 6 SV.
Step SV is a value (SV) at the end of the step.
• Setting range:
Scaling low limit to Scaling high limit
time
1 00:00
PTN/STEP
indicator 6
lights up.
Step 6 time
• Sets Step 6 time.
Step time is the processing time of the step.
• Setting range:
----, 00:00 to 99.59 (Time unit follows the selection in [Step time unit].)
If the key is pressed at 00:00, ---- will appear.
If ---- is set, Fixed value control will be performed using Step 6 SV.
_pid
1 ///1
PTN/STEP
indicator 6
lights up.
Step 6 PID block number
• Selects PID block number used for Step 6.
• Selection item:
1 to 10
temp
1 ///0
PTN/STEP
indicator 7
lights up.
Step 7 SV
• Sets Step 7 SV.
Step SV is a value (SV) at the end of the step.
• Setting range:
Scaling low limit to Scaling high limit
