- 49 -
• High/Low limit range alarm • High/Low limit range independent alarm
(Fig. 8.2-5) (Fig. 8.2-6)
• Process high alarm • Process low alarm
(Fig. 8.2-7) (Fig. 8.2-8)
• High limit with standby alarm • Low limit with standby alarm
(Fig. 8.2-9) (Fig. 8.2-10)
• High/Low limits with standby alarm • High/Low limits with standby independent alarm
(Fig. 8.2-11) (Fig. 8.2-12)
