Setting Item, Function, Setting Range
t1on
1 00:00
TS1 output ON time
• Sets TS1 output ON time.
• Setting range:
00:00 to 99:59 (Time unit follows the selection in [Step time unit].)
Available when/015 (Time signal output) is selected in [Event output EV1 allocation].
a2//
1 ///0
EV2 alarm value
• Sets EV2 alarm value.
EV2 alarm value matches EV2 low limit alarm value in the following cases:
004 (High/Low limits independent alarm), 006 (High/Low limit range
independent alarm) or 012 (High/Low limits with standby independent alarm)
is selected in [Event output EV2 allocation].
• Setting range: Same as those of EV1 alarm value.
Available when /001 (High limit alarm) to /
(
012 High/Low limits with standby
independent alarm) is selected in [Event output EV2 allocation].
a2h/
1 ///0
EV2 high limit alarm value
• Sets EV2 high limit alarm value.
• Setting range: Same as those of EV1 alarm value.
Available when /004 (High/Low limits independent alarm), /006 (High/Low limit range
independent alarm) or /012 (High/Low limits with standby independent alarm) is selected
in [Event output EV2 allocation].
t2of
1 00:00
TS2 output OFF time
• Sets TS2 output OFF time.
• Setting range:
00:00 to 99:59 (Time unit follows the selection in [Step time unit].)
Available when /015 (Time signal output) is selected in [Event output EV2 allocation].
t2on
1 00:00
TS2 output ON time
• Sets TS2 output ON time.
• Setting range:
00:00 to 99:59 (Time unit follows the selection in [Step time unit].)
Available when/015 (Time signal output) is selected in [Event output EV2 allocation].
a3//
1 ///0
EV3 alarm value
• Sets EV3 alarm value.
EV3 alarm value matches EV3 low limit alarm value in the following cases:
004 (High/Low limits independent alarm), 006 (High/Low limit range
independent alarm) or 012 (High/Low limits with standby independent alarm)
is selected in [Event output EV3 allocation].
• Setting range: Same as those of EV1 alarm value.
Available when /001 (High limit alarm) to /
(
012 High/Low limits with standby
independent alarm) is selected in [Event output EV3 allocation].
a3h/
1 ///0
EV3 high limit alarm value
• Sets EV3 high limit alarm value.
• Setting range: Same as those of EV1 alarm value.
Available when /004 (High/Low limits independent alarm), /006 (High/Low limit range
independent alarm) or /012 (High/Low limits with standby independent alarm) is selected
in [Event output EV3 allocation].
