Characters,
Factory Default
Setting Item, Function, Setting Range
tros
/ pv//
Transmission output type
• Selects the transmission output type.
Converting the value (PV, SV, MV transmission) to analog signal
every 125 ms, outputs the value in current or voltage.
• When changing transmission output type, refer to Section “9.6 Items to be
Initialized by Changing Settings” (p.104).
• Selection item:
pv// PV transmission
sv// SV transmission
mv// MV transmission
Available when EIT option is ordered.
trlh
/ 1370
Transmission output high limit
• Sets the Transmission output high limit value.
(This value correponds to 20 mA in direct current output.)
Outputs Transmission output low limit value if Transmission output high
limit and low limit value are the same.
If SV or MV transmission is selected, outputs 4 mA at the time of Program
control STOP (in Standby).
• Setting range:
PV, SV transmission: Transmission output low limit to Input range high limit
Direct current, voltage input: -2000 to 10000 (The placement of the decimal
point follows the selection.)
MV transmission: Transmission output low limit to 105.0%
Available when EIT option is ordered.
trll
/ -200
Transmission output low limit
• Sets the Transmission output low limit value.
(This value correponds to 4 mA in direct current output.)
Outputs Transmission output low limit value if Transmission output high
limit and low limit value are the same.
If SV or MV transmission is selected, 4 mA is output while in Program control
STOP (in Standby).
• Setting range:
PV, SV transmission: Input range low limit to Transmission output high limit
Direct current, voltage input: -2000 to 10000 (The placement of the decimal
point follows the selection.)
MV transmission: -5.0% to Transmission output high limit
Available when EIT option is ordered.
m_s/
/ min/
Step time unit
• Selects the Step time unit.
• Selection item:
min/ Hours : Minutes
sec/ Minutes : Seconds
