SICK FLOWSIC100 Flare User Manual

Assembly and Installation
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 133
Subject to change without notice
Version in 19” rack
Fig. 65 MCUP connections for 19" variant (without explosion protection)
1 Power supply unit 4 I/O module option
2 Display module 5 Terminal connection for power supply 90...250 V AC
3 Slot for interface module option 6 Terminal connection for wiring by customer
6
5
4
3
2
1
