Chapter 5 ONLINE HELP SOPAS
LECTOR®620
100 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013778/Y269/2013-11-27
Parameters
DLCS – Device list separated by comma List of all connected devices separated by a
comma
DLBS – Device list separated by blank List of all connected devices separated by a
blank space
DN – Device number Device number alternatively configured in the
fieldbus; number is identical to device ID by
default
DIN – Increment read by device Increment read by device
SID – Symbol ID Symbol ID
More object-related data… Description
FIX1 – Fix defined string 1 User-defined string 1
FIX2 – Fix defined string 2 User-defined string 2
FIX3 – Fix defined string 3 User-defined string 3
TT – Reading gate duration in ms Reading gate duration in ms
OTL – Trigger length in mm Trigger length in mm
NZ – Number of mismatches Number of mismatches (codes which do not ful-
fill the match code condition)
NY – Number of no matches Number of objects without any match
GNC – Global number of codes Number of codes
NVRB – Global number of valid released codes Number of valid released codes
NC – Number of reading gates Number of reading gates
DID – Device ID Device ID
SCGR – Superordinate counter: Good Read Superordinate Good Read counter; remains in
case of a new parameterization (reset via power
cycle)
SCNR – Superordinate counter: No Read Superordinate No Read counter; remains in case
of a new parameterization (reset via power cycle)
DEVN – Device name Device name
APC01 – Application counter 1 Definable counter 1
APC02 – Application counter 2 Definable counter 2
APC03 – Application counter 3 Definable counter 3
APC04 – Application counter 4 Definable counter 4
APC05 – Application counter 5 Definable counter 5
APC06 – Application counter 6 Definable counter 6
APC07 – Application counter 7 Definable counter 7
APC08 – Application counter 8 Definable counter 8
APC09 – Application counter 9 Definable counter 9
APC10 – Application counter 10 Definable counter 10
TS – Time stamp Time stamp of reading gate (start reading gate)
RR – Read rate Ratio between Good Reads (SCGR) and number
of reading gates
OGA – Distance between two objects Distance to previous object in mm
Match counters… Description
Match1 Counts how often Condition Match1 was fulfilled
(object-related)
More… Description
