ONLINE HELP SOPAS Chapter 5

LECTOR®620

Parameters

5.4.2.1.11 Of

If the CAN signal source is selected under the Start by parameter, the Of parameter can be

used to enter the CAN address of a device from the CAN network. This device receives a sui-

table trigger signal and distributes it to the other devices in the CAN network.

5.4.2.1.12 Trigger echo on

If the C

OMMAND signal source is selected under the Start by parameter, the command is sent

from the LECTOR

620 as a response to the controller if the Trigger echo on parameter is

activated.

As a result, the controller can check transmitted SOPAS commands.

5.4.2.1.13 Reading gate on

Pressing the Reading gate on button manually opens the reading gate.

So that you can test the current settings, all outputs, output strings and image transmission

function in accordance with the configuration. The reading gate is closed in accordance with

the configuration.

This function is ideally suited to testing operating mode and simulating a machine trig-

ger with a mouse click.

5.4.2.1.14 Reading gate off

Pressing the Reading gate off button manually closes the reading gate.

This enables you to conclude the reading operation even if the configured condition for au-

tomatically closing the reading gate does not occur.

This function is ideally suited to testing operating mode and simulating a machine trig-

ger with a mouse click.

5.4.2.2 Trigger distribution

The communication from the trigger signal to network users is defined in the Trigger distri-

bution group.

In a network with several reading devices, it is often sufficient to use a photoelectric switch

or connect a reading device to the control. The trigger signal is then distributed to the net-

work users.

The Trigger distribution function allows trigger signals and the number of photoelectric swit-

ches in use to be significantly reduced. This leads to a significant reduction in system com-

plexity and cost.
